1, Professional digital processing system. Stereo DSP ECHO.
2, 4 levels plus-minus of music key controlled system, 6 groups of memory function.
3, MAX and initial volume of MIC, Music, effect can be set. 2 levels of lock function.
4, USB connector is available provided with PC.
5, Singing(hot-dancing) can switch automatically or by user.
6, With easy/professional mode exchanged.
① MIC and Music are with multi bands PEQ.Effectvolume, mode.HPF/LPF can set
② Center output channel comes with HPF, LPF. 2 bands PEQ.Music, MIC and reverb mixing rate can be adjusted independently.
③ SUB output channel comes with HPF, LPF, 2 bands PEQ, delay, Music, MIC and reverb mixing rate can be adjusted independently.
① MIC, Music and effect are with 3 bands EQ (treble, middle and bass).
② Center output channel is with volume, HPF, LPF, Music, MIC and reverb mixing rate can be adjusted independently.
③ SUB output channel is with volume, HPF, LPF, polarity.
Model |
KA-300 |
KA-500 |
Output power |
300W*2 8Ω |
500W*2 8Ω |
S/N |
MIC : 75dB 1kHz 0dB Music : 90dB |
|
THD |
MIC : 0.3% 1kHz 0dB Music : 0.01% |
|
Sensitivity |
MIC : 15mV Music : 300V |
|
Input Impedance (Ω) |
MIC :10K ( Unbalanced ) Music :47K ( Unbalanced ) |
|
Frequency response |
20Hz-20kHz (±0.5dB,1kHz) |
|
Feedback |
5 Levels |
|
Crosstalk of channels |
85dB/1kHz |
|
Easy Mode |
MIC |
|
Professional Mode |
MIC: 7 PEQ + 7 bands PEQ + HPF, LPF |
|
Gross Weight |
16.8 KG |
20 KG |
Dimensions (L*W*H) |
615 x 595 x 145 (mm) |
